Magnetic Tir-Rod Hydraulic Cylinder

Magnetic Tie-Rod Hydraulic Cylinders are designed to provide reliable linear actuation with integrated position sensing for industrial hydraulic systems. Based on a robust tie-rod construction, these cylinders convert hydraulic fluid pressure into controlled mechanical motion while allowing precise detection of piston position through magnetic sensing. The built-in magnet on the piston enables the use of external magnetic switches, making these cylinders ideal for automated systems that require feedback, monitoring, or sequencing control.

Key Features:
Tie-rod construction for strong structural integrity and easy maintenance
The product mounted with induction magnet and sensor switch
Enables accurate position detection without direct mechanical contact
High operating pressure capability for stable and reliable performance
Applications:
Industrial automation equipment, machine tools, hydraulic fixtures, presses, material handling systems, and automated production lines where position sensing and reliable hydraulic actuation are required.
Customized service:
Can be customized according to provided drawings
Inquiry：sales@tab-sourcing.com
